ZIKUN ZC-520T XPON ONU With 1GE 3FE 1POTS 1USB WiFi CATV GPON ONT
Product Description
ZC-520T is a dual-mode(XPON) optical network terminal (ONT) supports automatic switching between GPON and EPON modes, is designed for the fiber to the home (FTTH) scenarios. ZC-520T complies with the ITU-T G.984 standard and IEEE802.3ah Standard, It has 10Mbps/100Mbps/1000Mbps adaptive GE interfaces, complying with IEEE802.3-2005 standards. The device offers 1* GE+3FE,1VoIP,1CATV RF,1USB and 2*2 11n wifi. It can provide serivces for Voice(VoIP),Catv Video,IPTV Video and highspeed internet access.
ZC-520T XPON 1GE+3FE+1USB+1POTS+WiFi+CATV+WDM+AGC ONU Terminal
Specifications
| Technical item | ZC-520T XPON 1GE+3FE+1POTS+1USB+WIFI+CATV+WDM+AGC |
| PON |
GPON/EPON mode adaptive ITU-T G.984 GPON standards,Support for backward compatibility with IEEE 802.3ah EPON Single mode fiber Receiving sensitivity: ≤-28dBm Transmitting optical power: 0~+4dBm Transmission distance: 20KM |
| LAN | Auto-adaptive 10 Mbit/s, 100 Mbit/s or 1000 Mbit/s,MAC address learning |
| POTS | . SIP/ H.248 . Call waiting, Inconditional Call Forward, Call Forward if Busy,Call Forward if no reply and Three-party calls. . G.711A/U, G.729 and G.722 encoding/decoding . T.30/T.38/G.711 fax mode . SDP protocol (RFC 2327 and RFC 4566) . DTMF |
| WiFi Feature |
. IEEE 802.11 b/g/n (2.4G) |
| USB | 1xUSB2.0 for storage |
| LED | 12, For Status of Power, PON,LOS,LAN1~4 ,TEL,USB,WiFi,WPS. |
| Operating condition |
Temperature: 0℃～+50℃ Humidity: 5%～90%(non-condensing) |
|
Storing condition |
Temperature : -30℃～+75℃ Humidity :5%～90%(non-condensing) |
| Power supply | DC 12V,1/1.5A |
| Power consumption | ≤10W |
| Dimension |
18.5CM*12.6CM*3.6CM(L×W×H) |
| Net weight | 0.4Kg |
Order Information
| Product model | Product specification | Chipset | SDRAM Memory |
| ZC-520T XPON | 1GE+3FE+1USB+1POTS+WiFi+CATV+WDM+AGC |
MTK |
64MB |
