Mesh Dual Band Gigabit WiFi 6 Router Smart 3000Mbps MU-MIMO
1GE WAN+3GE LAN+WiFi6 AX3000 Wireless Router adopt WiFi6 technology which has redefined home WiFi. Experience up to 3x faster speeds, higher capacity, and reduced congestion overall compared to the previous AC WiFi5 standard. The AX3000 4-stream dual-band WiFi6 wireless router reaches speeds of up to 3 Gbps, for a buffer-free 4K/HD streaming and gaming experience.
The WiFi6 router lets you connect even more devices via OFDMA technology, minimizing network congestion that occurs with too many connected devices. Intel's dual-core processor effortlessly handles all your streaming, gaming and smart home devices. ZC-R560 uses Beamforming technology to focus WiFi signal to your devices for more reliable coverage. The ZC-R560 is easy use and setup with WebUI.
Smart Dual-band Gigabit WiFi 6 Router
3000 Mbps | WiFi 6 | OFDMA Multi-User | One SSID for Dual Band
Features & Specification
Wireless Protocol |
2.4GHz IEEE 802.11 b/g/n 2T2R 5GHz IEEE 802.11a/n/ac/ax 2T3R |
Wireless Transfer Rate |
2.4G=576Mbps 5G=2400Mbps |
Antennas |
2*2.4G 5dBi fixed Antenna built-in 3*5G 5dBi fixed Antenna built-in |
External Interface |
1*WAN 10/100/1000Mbps 3*LAN 10/100/1000Mbps 1*DC JACK |
Buttons |
1*WPS 1*Reset 1*Power |
Indicator Lights |
Power, WAN, LAN, WIFI, WPS |
Power Dissipation |
<18W |
Size | L255*W165*H39 |
Temperature |
Operating Temperature: -10°C ~ +45°C Storage Temperature: -40°C ~ +70°C Storage Humidity: 5% ~ 95% Atmosphere Pressure: 86kPa ~ 106kPa |
WLAN |
Support 802.11 a/b/g/n/ac/ax protocol standard 20/40/80 /160 MHz Bandwidth Adaptation of channel MSSID + Guest network WPS: PBC/PIN WPA/WPA2/WPA3 |
Network protocols and features |
Connection mode: PPPoE/DHCP/Static IP IPv4, IPv6, IPv4/IPv6 DHCP v4/v6 Static routes (v4/v6), RIP NAT/ALG/DMZ/Virtual server ARP/ICMP/DNS Proxy NTP VLAN |
Management Function |
Web UI TR069 Online and local software upgrades Fault diagnosis |
Next Generation Firewall |
SBuilt-in firewall DoS, ARP Attack/Port scanning MAC/Port filtering |
QoS |
802.11e WMM Traffic classification Port-Based/VLAN/ IP IP flow control |
What is a mesh Wi-Fi router?
What is a mesh Wi-Fi router? Mesh systems join two or more Wi-Fi access points together, creating and sharing a single, seamless Wi-Fi network that can be expanded and set up to cover even the largest of homes or buildings.
If the Wi-Fi router that worked in your small apartment doesn't give you the wireless connectivity you want for a big house, then a mesh Wi-Fi router system may be the solution for you.
If you have a large home — at least 3,000 square feet — or one that has an unusual layout, more than two stories or interior brick walls, then you probably encounter Wi-Fi dead zones. This means your home could be a good candidate for a mesh system.
